GM-1000 Industrial PC with MXM GPU


9th/8th Gen Intel® Xeon®/Core™ Embedded GPU Computer, Supports 1x MXM 3.1 GPU Expansion Socket

PRODUCTS FEATURES
  • Supports 9th/8th Gen Intel® Xeon®/Core™ Processor up to 8 cores
  • Supports 1x MXM 3.1 Type A/B form factor GPU module expansion
  • 2x DDR4 SO-DIMM sockets, up to 2666MHz, 128GB
  • Supports wide operating temperature (-40°C - 70°C) and vibration/shock tolerance (5G/50G)
  • 260 mm x 200 mm x 85 mm compact footprint
  • Flexible functionality expansions:
    - M.2 E key (CNVi), full-size Mini-PCIe and M.2 M Key (NVMe SSD)
    - Proprietary CMI interface for various I/O expandability
    - Proprietary CFM interface for PoE+ or Power Ignition Sensing

MXM GPU Expansion

GPUs are the key to super-fast image processing. The MXM 3.1 Type A/B expansion slot supports modern MXM GPUs. Standard options are an Nvidia Quadro RTX3000/T1000 or AMD Radeon E9174 GPU, but upgrades to even faster MXM GPUs (up to 160 W) can further accelerate performance.

Generous 360W Power Budget Core Performance

The specialized power design of the GM-1000 provides a 360W power budget that counters the typical limitations of fanless embedded systems. A unique thermal design, combining independent cooling systems for CPU and GPU and extruded aluminum case with integrated copper heat piping, ensure operational reliability in the field.
