DA-1200-N97 Industrial Edge PC

SKU: DA-1200-N97-R10

Compact, Fanless Industrial Edge Computer

The DA-1200-N97-R10 is a  fanless embedded computer designed for industrial applications on the edge. Built around the Intel Alder Lake N97 processor, it delivers efficient computing power in a compact, rugged chassis, making it an ideal choice for IoT gateways, smart manufacturing, and factory automation.

Key Features

  • Intel Alder Lake-N97 Processor – Ensures efficient processing for industrial tasks.
  • Fanless Design – Passive cooling for silent and reliable operation.
  • Compact Form Factor – (150 x 105 x 52.3 mm), ideal for space-constrained environments.
  • Versatile Mounting Options – Supports wall, side, and DIN rail mounting for flexible installation.
  • Wide Operating Temperature Range – -40°C to 70°C, suitable for harsh environments.
  • Modular Expansion – Includes two M.2 Key B slots for storage/wireless modules and a CMI interface for additional I/O expansion.




 Specifications
Processor Intel Alder Lake-N97
Memory Supports up to 16GB DDR5 4800MHz SO-DIMM
Storage Supports 2.5" SATA HDD/SSD or half-slim SSD
Networking Dual 2.5GbE LAN ports for high-speed connectivity
Display Output 1 x DisplayPort (up to 4096 x 2304 @ 60Hz)
USB Ports 2 x USB 3.2 Gen2 (10Gbps)
Expansion 2 x M.2 Key B slots, 1 x Universal I/O Bracket, CMI interface for additional I/O
Power Input 9 to 48V DC, via 3-pin terminal block
Certifications UL, cUL, CB, IEC, EN 62368-1



Complete customizations available beyond the standard options offered for purchase on our e-store. Contact support for a consultation
